Phoenix Inverter 12/3000 120V VE.BUS
In stock
$ 1.358
In stock
Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds.
SinusMax - Superior engineering
Developed for professional duty, this range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.
Parallel and 3-phase operation capability
Up to 6 Inverters can operate in parallel to achieve higher power output. Six 24 V 5000 VA units, for example, will provide 24 kW / 30 kVA output power. Operation in 3-phase configuration is also possible.
Additional information
| Weight | 18,4 kg |
|---|---|
| Dimensions | 33 × 44,5 × 29,5 cm |
| batteryVoltageNominal | 12 V |
| dCInputVoltageRange | [9.5, 17] V |
| aCOutputVoltage | 120 V |
| frequencySelect | 50Hz or 60Hz |
| contPowerVA25 | 3, 000 VA |
| contPowerW25 | 2, 400 W |
| contPowerW40 | 2, 200 W |
| contPowerW65 | 1, 700 W |
| peakPowerRating | 6, 000 W |
| maxEfficiency | 93 % |
| zeroLoadPower | 20 W |
| zeroLoadPowerAES | 15 W |
| zeroLoadPowerSearch | 8 W |
| programmableRelay | AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC |
| remoteOnOffTerminal | 1 |
| communicationPort | VE.Bus |
| fullyProgramable | 1 |
| parallel3phase | 1 |
| protections | Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple |
| Cooling | 1 |
| maxHumidity | 95 % |
| batteryConnection | M8 bolts (two for positive and two for negative connection) |
| acConnection | Screw terminals |
| remoteTerminal | Screw terminal two pole |
| relayTerminal | Screw terminal 3-pole |
| colour | Blue (RAL 5012) |
| material | Aluminium |
| protectionCategory | IP21 |
| weight | 18 kg |
| height | 362 mm |
| width | 258 mm |
| depth | 218 mm |
| safety | EN-IEC 60335-1 |
| eMC | EN 55014-1, EN 55014-2 |
